Sale!

BMXDAI0814

Original price was: $ 274.00.Current price is: $ 174.00.

In stock

Categories: ,

Description

Main
range of product Modicon X80
product or component type Discrete input module
discrete input number 8
discrete input type Isolated per channel
input type Capacitive
discrete input voltage 100…120 V AC
discrete input current 5 mA
Complementary
input compatibility 2-wire proximity sensor conforming to IEC 60947-5-2
2-wire proximity sensor conforming to IEC 61131-2 type 3
network frequency 50/60 Hz
network frequency limits 47…63 Hz
Sensor power supply 85…132 V
current state 1 guaranteed >= 2.5 mA
current state 0 guaranteed <= 1 mA
input impedance 13000 Ohm
insulation resistance > 10 MOhm 500 V DC
power dissipation in W 2.35 W
AC activation response time 10 ms
AC deactivation response time 20 ms
typical current consumption 61 mA at 3.3 V DC
MTBF reliability 1700000 H
protection type 1 external fuse per channel0.25 A fast blow
status LED 1 LED (green) module operating (RUN)
1 LED per channel (green) channel diagnostic
1 LED (red) module error (ERR)
1 LED (red) module I/O
net weight 0.115 kg
Environment
IP degree of protection IP20
directives 2014/35/EU – low voltage directive
2014/30/EU – electromagnetic compatibility
dielectric strength 1780 V AC at 50/60 Hz 1 min
vibration resistance 3 gn
shock resistance 30 gn
ambient air temperature for storage -40…85 °C
ambient air temperature for operation 0…60 °C
relative humidity 5…95 % at 55 °C without condensation
operating altitude 0…2000 m
2000…5000 m with derating factor
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Weight 152.0 g
Package 1 Height 5.5 cm
Package 1 width 11.0 cm
Package 1 Length 12.0 cm
Unit Type of Package 2 S02
Number of Units in Package 2 15
Package 2 Weight 2.63 kg
Package 2 Height 15.0 cm
Package 2 width 30.0 cm
Package 2 Length 40.0 cm
