Sale!

140CPS11100

Original price was: $ 845.00.Current price is: $ 650.00.

In stock

Category:

Description

Main
range of product Modicon Quantum automation platform
product or component type Power supply module
power supply type Standalone
Complementary
input voltage 120…230 V (100…276 V) AC 47…63 Hz
input current 200 mA at 230 V
400 mA at 115 V
inrush current 10 A 230 V
20 A 115 V
rated power in VA 50 VA
associated fuse rating 1.5 A, slow-blow
harmonic distortion <= 10 % of fundamental rms value
output voltage 5.1 V DC
power supply output current 3 A standalone
output overvoltage protection Internal
output overload protection Internal
power dissipation 2 + (3 x Iout) where Iout is in A
local signalling 1 LED (green) for power (PWR OK)
marking CE
module format Standard
net weight 0.65 kg
Environment
standards UL 508
CSA C22.2 No 142
product certifications CUL
FM Class 1 Division 2
resistance to electrostatic discharge 4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2
resistance to electromagnetic fields 10 V/m 80…2000 MHz conforming to IEC 801-3
ambient air temperature for operation 0…60 °C
ambient air temperature for storage -40…85 °C
relative humidity 95 % without condensation
operating altitude <= 5000 m
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Height 16.3 cm
Package 1 Width 4.5 cm
Package 1 Length 31.2 cm
Package 1 Weight 665.0 g
Unit Type of Package 2 S03
Number of Units in Package 2 7
Package 2 Height 30.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2 Weight 4.543 kg
