Description
| Range of product | Twido |
|---|---|
| Accessory / separate part category | Connection accessories |
| accessory / separate part type | Tap isolation box |
| Accessory / separate part designation | Tap isolation box |
| Accessory / separate part destination | RS485 serial link |
| Product specific application | Lines prepolarised (2 R 620 Ohm) RS485 line isolation Line end adaptor (RC 120 Ohm, 1 nF) |
| Range compatibility | Twido programmable controller Modicon M238 logic controller |
|---|---|
| [Us] rated supply voltage | 24 V |
| Supply circuit type | DC |
| supply | External |
| Electrical connection | 1 screw terminal block 2 connectors RJ45 (for tap-off) |
| mounting support | 35 mm symmetrical DIN rail |
| Net weight | 0.1 kg |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 6.6 cm |
| Package 1 Width | 6.5 cm |
| Package 1 Length | 12.0 cm |
| Package 1 Weight | 156.0 g |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 4.191 kg |
| Unit Type of Package 3 | P12 |
| Number of Units in Package 3 | 768 |
| Package 3 Height | 75 cm |
| Package 3 Width | 120 cm |
| Package 3 Length | 80 cm |
| Package 3 Weight | 150 kg |
